HEUI Test Bench with Imported Flow Sensor Code Generation and Real-time Display Injection/Return Curves for Common Rail Injector Testing
  • name
  • name
  • name
  • name
  • name
  • name

HEUI Test Bench with Imported Flow Sensor Code Generation and Real-time Display Injection/Return Curves for Common Rail Injector Testing

MOQ: 1
Price: 7428.57
Details Information
Product Description
Detail Information
Certification
CE, ISO
Model NO.:
JZ-326S
Motor Power:
4 Kw / 5.5 Kw
Power:
3-Phase 4-Wire 380V 50/60Hz
Rail Pressure:
0-2700 Bar
Rail Pressure Precision:
5 Bar
Filter Precision:
< 5 Um
Oil Tank Volume:
20 L
Diesel Tank Volume:
20 L
Fuel Temperature:
38-42 'c
Net Weight:
610 Kg
Nozzle Sensor:
Gear Flow Sensor: 2 PCS
Engine Oil Sensor:
Gear Flow Sensor: 1 PCS
Machine Dimensions:
1440*1010*1640 Mm
Control Circuit Voltage:
DC24V / DC12V
ECU Internal Boost:
0-200 VDC (Max)
Highlight:

Imported Flow Sensor HEUI Test Bench

,

Code Generation Common Rail Injector Test Bench

,

Real-time Display Injection/Return Curves Diesel Injector Diagnostic Machine

Product Description
HEUI Common Rail Laboratory Equipment Measuring Instruments Car Diagnostic Tool Test Bench - JZ-326S
The JZ-326S common rail injector test bench features full automatic control for convenient repair and testing of Euro-3 and Euro-4 injectors. This advanced equipment can test thousands of injectors including Bosch, Delphi, Denso, Siemens, and Caterpillar models, providing comprehensive experimental data.
HEUI Test Bench with Imported Flow Sensor Code Generation and Real-time Display Injection/Return Curves for Common Rail Injector Testing 0 HEUI Test Bench with Imported Flow Sensor Code Generation and Real-time Display Injection/Return Curves for Common Rail Injector Testing 1 HEUI Test Bench with Imported Flow Sensor Code Generation and Real-time Display Injection/Return Curves for Common Rail Injector Testing 2 HEUI Test Bench with Imported Flow Sensor Code Generation and Real-time Display Injection/Return Curves for Common Rail Injector Testing 3
Standard Functions
  • All HEUI injectors can be tested
  • Engine oil/diesel leakage detection
  • Software-controlled oil supply switch
  • Separate diesel pump for HEUI fuel supply
  • Manual or automatic oil pressure adjustment
Sealing Tests
  • Diesel static sealing test
  • Engine oil static sealing test
  • Dynamic oil return amount measurement
Fuel Injection Tests
  • Maximum fuel injection test
  • Medium speed injection test
  • Idle fuel injection test
  • Pre-injection test
  • Start fuel injection amount test
  • Oil return amount under various conditions
Additional Capabilities
  • Common rail injector testing
  • Piezo fuel injector testing
  • Bosch IQA code generation
  • Real-time injection/return curve display
Optional Functions
  • 4-pin injector testing
  • Denso injector QR code support
  • Siemens VDO-IIC coding
  • Delphi C2i, C3i coding
  • Bosch piezo IMA, ISA coding
  • Cummins injector correction code
HEUI Test Bench with Imported Flow Sensor Code Generation and Real-time Display Injection/Return Curves for Common Rail Injector Testing 4
Technical Specifications
Parameter Specification
Output 4 KW / 5.5 KW
Power 3-Phase 4-Wire 380V 50/60HZ
Rail Pressure 0~2700 Bar
Rail Pressure Precision ±5 Bar
Tank Volume 20L/20L
Fuel Temperature 40±2ºC
Filter Precision < 5μm
Gross Weight 500 kg
Packing Size 1450×1050×1650 mm
Speed Control Converter Control
Temperature Control Air-Cooled Heat Dissipation
Nozzle Sensor Imported Original Elliptical Type Flow Sensor
Language Support English, Spanish, Russian, etc.
Why Choose Our Product
  • 20 years of diesel fuel engine system maintenance experience
  • Independent design and development team
  • Top-quality components from industry-leading suppliers
  • Strict quality control and comprehensive after-sales service
  • Customization options for appearance and color
  • Free remote assistance services
Contact Information
Keith/Djamel | Sales
Phone: +86 1891 5270881
Company: Wuxi Jia Miao Auto Technology Co., Ltd
Address: No. 117 Xinzhuang Road, Zhutang Town, Wuxi City, Jiangsu Province, China
Website: jm888888.en.made-in-china.com
Tags:

Injector Testing Machine,

Common Rail Instruments,

Car Diagnostic Tool Test Bench
